PoolWorld's domestic hot water tank and buffer tank adopt high-quality stainless steel as the inner tank, which can effectively prevent rust and corrosion, good heat preservation, more health and safety, and long service life.
Feature
Tank volume 150L~300L
Built-in Corrugated Pipe Coil
SUS304 Inner tank is strong and durable, long service life.
Fast heating, long-lasting heat storage, safe and efficient
Specifically designed for air source heat pump system
Specification
Domestic Hot Water Tank | ||||||
Model | PD-150L | PD-200L | PD-200L-1 | PD-250L | PD-300L | PD-300L-1 |
Tank Volume(L) | 150 | 200 | 200 | 250 | 300 | 300 |
Inner Tank material | SUS304 | SUS304 | SUS304 | SUS304 | SUS304 | SUS304 |
Inner Tank Thickness(mm) | 1.0 | 1.2 | 1.2 | 1.4 | 1.4 | 1.4 |
Shell Material | Color Plate | |||||
Shell Thickness(mm) | 0.4 | 0.4 | 0.4 | 0.4 | 0.4 | 0.4 |
Coil Material | SUS304 | SUS304 | SUS304 | SUS304 | SUS304 | SUS304 |
Coil Type | Corrugated Pipe | Corrugated Pipe | Corrugated Pipe | Ordinary Pipe | Corrugated Pipe | Corrugated Pipe |
Coil Specifications (mm) | φ25mm*15m | φ25mm*20m | φ25mm*20m | φ22mm*22m | φ25mm*20m | φ25mm*30m |
Coil Thickness(mm) | 0.3 | 0.3 | 0.3 | 1.0 | 0.3 | 0.3 |
Coil Area(㎡) | 1.6 | 2.2 | 2.2 | 1.5 | 2.2 | 3.3 |
Cold Water Inlet | G3/4" M | |||||
Hot Water Outlet | G3/4" M | |||||
Circulating Water Inlet | G1" M | G1" M | G1" M | G3/4" M | G1" M | G1" M |
Circulating Water Onlet | G1" M | G1" M | G1" M | G3/4" M | G1" M | G1" M |
Water Return | G3/4" M | G3/4" F | G3/4" F | G3/4" M | G3/4" M | G3/4" F |
Electric Heater Port | / | / | G1" F | / | / | G1" F |
Electric Heater (KW） | / | / | 3kW | / | / | 3kW |
Temperature Detection Port | G1/4" F | |||||
Anode Rod | G3/4" F | |||||
P/T Valve Port | / | G3/4" F | / | G3/4" F | ||
Sewage Outlet Port | G3/4" M | |||||
Working Pressure Bar | 8 | 8 | 8 | 8 | 8 | 8 |
Insulation Layer | Polyurethane | |||||
Insulation Layer Thickness(mm) | 50 | 45 | ||||
Product Size(mm) | φ470*1525 | φ520*1575 | φ520*1575 | φ560*1605 | φ560*1885 | φ560*1885 |
Package Size(mm) | 540*540*1530 | 595*595*1590 | 595*595*1590 | 630*630*1670 | 630*630*1950 | 630*630*1950 |
